Elastic Search Curator to clear old logs/indices using Helm Chart

What is Elasticsearch Curator?

Curator is a tool from Elastic (the company behind Elasticsearch) to help manage your Elasticsearch cluster. You can create, backup, and delete some indices, Curator helps make this process automated and repeatable. Curator is written in Python, so it is well supported by almost all operating systems. It can easily manage the huge number of logs that are written to the Elasticsearch cluster periodically by deleting them and thus helps you to save the disk space.

Below mentioned steps, explains how you can clear old indices from your cluster.

1.) Configuring Elasticsearch Curator using Yaml

A very elegant way to configure and automate Elasticsearch Curator execution is using a YAML configuration. Create the file ‘values.yml’ with the following content.

# Default values for elasticsearch-curator.
# This is a YAML-formatted file.
# Declare variables to be passed into your templates.

cronjob:
  # At 01:00 every day
  schedule: "0 1 * * *"
  annotations: {}
  labels: {}
  concurrencyPolicy: ""
  failedJobsHistoryLimit: ""
  successfulJobsHistoryLimit: ""
  jobRestartPolicy: Never

pod:
  annotations: {}
  labels: {}

rbac:
  # Specifies whether RBAC should be enabled
  enabled: false

serviceAccount:
  # Specifies whether a ServiceAccount should be created
  create: true
  # The name of the ServiceAccount to use.
  # If not set and create is true, a name is generated using the fullname template
  name:


psp:
  # Specifies whether a podsecuritypolicy should be created
  create: false

image:
  repository: untergeek/curator
  tag: 5.7.6
  pullPolicy: IfNotPresent

hooks:
  install: false
  upgrade: false

# run curator in dry-run mode
dryrun: false

command: ["/curator/curator"]
env: {}

configMaps:
  # Delete indices older than 7 days
  action_file_yml: |-
    ---
    actions:
      1:
        action: delete_indices
        description: "Clean up ES by deleting old indices"
        options:
          timeout_override:
          continue_if_exception: False
          disable_action: False
          ignore_empty_list: True
        filters:
        - filtertype: age
          source: name
          direction: older
          timestring: '%Y.%m.%d'
          unit: days
          unit_count: 7
          field:
          stats_result:
          epoch:
          exclude: False
  # Having config_yaml WILL override the other config
  config_yml: |-
    ---
    client:
      hosts:
        - CHANGEME.host
      port: 9200
      # url_prefix:
      # use_ssl: True
      # certificate:
      # client_cert:
      # client_key:
      # ssl_no_validate: True
      # http_auth:
      # timeout: 30
      # master_only: False
    # logging:
    #   loglevel: INFO
    #   logfile:
    #   logformat: default
    #   blacklist: ['elasticsearch', 'urllib3']
resources: {}
  # We usually recommend not to specify default resources and to leave this as a conscious
  # choice for the user. This also increases chances charts run on environments with little
  # resources, such as Minikube. If you do want to specify resources, uncomment the following
  # lines, adjust them as necessary, and remove the curly braces after 'resources:'.
  # limits:
  #  cpu: 100m
  #  memory: 128Mi
  # requests:
  #  cpu: 100m
  #  memory: 128Mi

priorityClassName: ""

# extraVolumes and extraVolumeMounts allows you to mount other volumes
# Example Use Case: mount ssl certificates when elasticsearch has tls enabled
# extraVolumes:
#   - name: es-certs
#     secret:
#       defaultMode: 420
#       secretName: es-certs
# extraVolumeMounts:
#   - name: es-certs
#     mountPath: /certs
#     readOnly: true

# Add your own init container or uncomment and modify the given example.
extraInitContainers: {}
  ## Don't configure S3 repository till Elasticsearch is reachable.
  ## Ensure that it is available at http://elasticsearch:9200
  ##
  # elasticsearch-s3-repository:
  #   image: jwilder/dockerize:latest
  #   imagePullPolicy: "IfNotPresent"
  #   command:
  #   - "/bin/sh"
  #   - "-c"
  #   args:
  #   - |
  #     ES_HOST=elasticsearch
  #     ES_PORT=9200
  #     ES_REPOSITORY=backup
  #     S3_REGION=us-east-1
  #     S3_BUCKET=bucket
  #     S3_BASE_PATH=backup
  #     S3_COMPRESS=true
  #     S3_STORAGE_CLASS=standard
  #     apk add curl --no-cache && \
  #     dockerize -wait http://${ES_HOST}:${ES_PORT} --timeout 120s && \
  #     cat <<EOF | curl -sS -XPUT -H "Content-Type: application/json" -d @- http://${ES_HOST}:${ES_PORT}/_snapshot/${ES_REPOSITORY} \
  #     {
  #       "type": "s3",
  #       "settings": {
  #         "bucket": "${S3_BUCKET}",
  #         "base_path": "${S3_BASE_PATH}",
  #         "region": "${S3_REGION}",
  #         "compress": "${S3_COMPRESS}",
  #         "storage_class": "${S3_STORAGE_CLASS}"
  #       }
  #     }

securityContext:
  runAsUser: 16  # run as cron user instead of root

You can modify the above values.yaml according to the requirements, some modifications are suggested below:

  schedule: "0 1 * * *"

* represents all the possible numbers for that position

Schedule Cron Job: In the above code, at line number 7, the Cron Job is Scheduled to run at 1 AM every day. You can schedule your Cron Job accordingly, below is the syntax of Cron Job for your reference.

client:
  hosts:
    - CHANGEME.host

Elasticsearch host endpoint: In the above code, from line number 79 onwards you can specify multiple Elasticsearch host endpoints under the hosts.

In Cluster Elasticsearch services can be provided using the syntax: .
Example: es1-elasticsearch-client.monitoring

    filters:
    - filtertype: age
      source: name
      direction: older
      timestring: '%Y.%m.%d'
      unit: days
      unit_count: 7
      field:
      stats_result:
      epoch:
      exclude: False

Delete Old Indices: You can specify how old the indices should be, to get deleted. At line number 69 of the above code, unit_count specifies the indices that are older than 7 days will be deleted.

2.) Install Elasticsearch Curator using Helm

Helm Chart will create a Cron Job to run Elasticsearch Curator. To install the chart, use the following command:

$ helm install stable/elasticsearch-curator

3.)Remove Elasticsearch Curator

To remove the Elasticsearch Curator, use the following command:

$ helm delete es1-curator --purge
